Wavelength Adjustable Monocolour Light Source
7-LX500-W15
7-L series wavelength adjustable m
onochromatic light source
The main body of the 7-L series wavelength adjustable monochromator light source is a wide spectrum light source (deuterium lamp, halogen tungsten lamp, xenon lamp or composite light source) and a wide spectrum monochromator. In addition, the 7IFW6 filter wheel is also equipped to eliminate multiple spectra, and the outlet of the light source can be equipped with a collimation or convergence mirror group according to the user's needs, and can be equipped with an adjustable diaphragm to change the size or energy of the outgoing spot. The SR540 Chopper mount is also available for users who need to connect the chopper. For special users, we also offer tailor-made services, such as different models of SIGNAL RECOVERY choppers and connection to various optical fibers. ,
Product features:
1, the stability of the light source is good, the monochromator has high repetition accuracy, and high resolution
2, the light source and monochromator in the teaching reserve chopper mounting base
3, the special software can control the continuous adjustable output bandwidth
4, the system is fixed on an optical plate, the light path is stable, high integration
5, can be built according to the needs of various types of adjustable monochromatic light source: fiber output mode, space output mode, integrating ball output mode, etc
